Design Portfolio
Project: MONARCH
Client: Caterpillar Financial
Design: Exterior/Interior
Year: 2011
The 151-foot semi-displacement Monarch yacht features a balance of elegance and strength, form and function, performance, range and comfort. The yacht has a flared hull design with a hard chine to
deflect spray, and high sheer, capturing a full beam arrangement forward of amidships. Efficiency is increased thanks to her bulbous bow.
MONARCH's modern interior by Jonathan Quinn Barnett, fills in the vast spaces achieved by a beam of 30'9''. The contemporary interior is perfectly complemented by the bold exterior styling.
The 46 metre M/Y MONARCH offers accommodation in five luxurious and well appointed cabins to 10 guests in total. These include the full beam master stateroom on the main deck, two king cabins, one
queen cabin and one twin berth stateroom.
Monarch boasts impressive outdoor deck spaces, a well balanced mix of sheltered and open venues, expansive settings and secluded corners, which are suitable for relaxation, as well as other social
occasions.
The yacht is wheelchair accessible, with extra wide doors, spacious walkways and a centrally located elevator providing convenient access to all four decks.
Powered by twin Cat 3512 B series engines, the yacht Monarch can attain a maximum speed of up to 20 knots, a cruising speed of 18 knots with a range of 3,000 nautical miles at 12 knots. The
superyacht is ABS and MCA certified, under 500 gross tons.
Adobe Acrobat document [3.5 MB]
Project: DELTA 55 Meter
Client: confidential
Design: Interior
Year: 2010
Built in the United States by the renowned Delta Marine yard, the DELTA 55 metre superyacht has an exterior design by Langan Design Associates in collaboration with JQB Ltd. The interior design is by JQB Ltd.
Project: CRESCENT 144
Client: confidential
Design: Exterior/Interior
Year: 2012
Media: Charterworld
In this project, JQB Ltd has shaped a dramatic exterior profile offering both contemporary style and disciplined proportions for timeless appeal. Working with a proven hull form by Jack Sarin, Jonathan has developed an interior arrangement that's as functional and spacious as it is innovative, and offers strictly deluxe accommodations for ten in an environment exceptionally well-suited for private enjoyment and charter service.
Large windows in the salon and sky lounge open social areas to daylight and to a panoramic view of the passing scenery. The Crescent 144's interior arrangement offers a wide range of customizing options, including an innovative main-deck layout that features a full-service bar aft of the salon, where it's encircled by view windows and positioned to provide convenient service to guests inside and on the aft deck. Among other attributes are an on-deck master suite with an office positioned outboard for yet another spectacular view, up to four guest suites on the lower deck, skylounge with full-service bar and a spacious sun deck with hot tub and barbecue. A large transom door transforms the swim platform into a portable beach and base for fishing, diving and enjoying water toys.
Exterior deck areas have been designed for a variety of uses, from elegant entertaining to sunning and enjoying the view. The sun bridge deck includes a large jetted tub and adjacent service bar with barbecue for casual relaxation and entertaining, and a composite hardtop creating a just-right balance of sun and shade.
Lower-deck accommodations include two VIP and two guest suites, with direct access from adjacent crew quarters to allow efficient room make-up. Equally thoughtful details abound throughout this innovative yacht, and include a main-level bar serving guests in the salon and on the aft deck, a day head just off the swim step for the convenience of swimmers, and an intimate seating/sunning area on the foredeck, a secluded retreat for the enjoyment of owners and guests alike.
Adobe Acrobat document [3.3 MB]
Project: EVO 55 Meter
Client: EVOLUTION YACHTS
Design: Exterior/Interior
Year: 2007
This luxurious and world-class long-range cruiser can accomodate 12 guests and 14 crew in genuine style.
Along with her plentiful interior and exterior spaces, paired with classic, coastally-inspired décor, is the inclusion of an innovative 'beach club' at her stern. A large aft and two side shell doors fold down to create generous swim platforms and open-up an expansive interior complete with bar, hot-tub and toy storage, creating an entirely new space for waterside entertaining.
Powered by two 1560hp Caterpillar 3512B engines, she has a range of 4,500nm at 12 knots, and will reach a top speed of 16-18 knots.
Project: Horizon Yachts - Vision 65
Client: Emerald Pacific Yachts
Design: Exterior/Interior
Year: 2006-current
The new Horizon V65 features ZF joystick control for effortless single handed maneauvering and a industry-leading 18'-10" beam allowing for three en suite staterooms. The V65 also features a next-generation electrical system with state of the art low-current LED lighting, a complete gourmet galley with seating for formal and casual dining and enormous enclosed storage locker or optional seating area with a table.
Adobe Acrobat document [1.8 MB]
Project: QUEENSHIP 73
Client: QUEENSHIP
Design: Exterior/Interior
Year: 2009
Media: Charterworld
Experienced yacht owners will immediately recognize the flawless exterior contours and contemporary styling of the Queenship 74. This new vessel offers the convenience and versatility of its mini-yacht dimensions in combination with an extensive list of luxurious appointments and onboard amenities.
On the broad, covered aft deck, a built-in dining/cocktail banquette faces a service bar with space for an optional barbecue. The salon offers comfortable seating surrounded by large view windows. Just forward, the raised pilot house encloses a fully-equipped galley, and a raised dining/observers’ settee overlooking the lower helm to allow a spectacular view forward and to either side.
Design details, plans, and more info available at JQB Ltd.
Project: AERIE
Client: confidential
Design: Exterior/Interior
Year: 2001
AERIE is a lightweight, semi-displacement, tri-deck motor-yacht with proven excellence in performance, technical innovation and dramatic design touches.
Project: JQB 350RL
Design: Exterior/Interior
Year: 2008
The JQB 350RL is an all carbon fiber, lightweight, high performance yacht that is responsive and agile - yet easy to sail The 350RL has 5' 10" of standing headroom and comfortable sleeping berths for three. With a large v-berth, and a full sized head, the 350RL is as accommodating as it is fast. A boat designed for those that love the pure enjoyment of sailing.
Specs:
LOA:
35’2”
Sail area: 600 Sq. Ft.
Beam:
9’10”
Downwind: 1275 Sq. Ft.
Draft: 7’
6”
Engine: 12 Hp Yamaha sail drive
Displacement: 4,000
Lbs.
Mast: Zyvex Carbon Fiber
Ballast: 2,400
Lbs.
Rudder: VARA rudder system
